Volkswagen Golf Service & Repair Manual: Removing and installing central locking SAFELOCK function warning lamp -K133

Volkswagen Golf Service & Repair Manual / Electrical system / Lights, lamps, switches inside, anti- theft system / Lights / Removing and installing central locking SAFELOCK function warning lamp -K133

Removing
–  Remove front door trim panel → General body repairs, interior; Rep. gr.70.

–  Unclip central locking SAFELOCK function warning lamp -K133--1- by pressing locking lugs together -arrows- and remove from door trim panel.


Removing and installing central locking SAFELOCK function warning lamp -K133

–  Pull off connector -1- of central locking SAFELOCK function warning lamp -K133--2-.
Installing
Installation is carried out in reverse order of removal.
–  Test functionality.
