Assembly overview - steering column switch module, with mechanical ignition
lock
1 -
Ignition key
2 -
Lock cylinder
Removing and installing
→ Chapter
3 -
Immobiliser reader coil -D2-
Removing and installing
→ Chapter
4  ...
Removing and installing heat shield for centre exhaust system
Note
The removal and installation procedures may have to be modified
slightly depending on engine fitted.
Removing
–
Removing rear exhaust system
→ Rep. gr.26.
–
Loosen lock washers -2-.
...
Removing and installing alarm horn -H12-
Removing
–
Remove plenum chamber cover
→ General body repairs, exterior; Rep. gr.50.
–
Remove nuts -3-.
–
...
