Volkswagen Golf Service & Repair Manual: Adhesion promoter

Volkswagen Golf Service & Repair Manual / General information, paint / Genuine products / SprayMax System / Adhesion promoter

Designation:

Adhesion promoter -LLS MAX 015- for plastics

Issued 10.2012

Product description

The adhesion promoter -LLS MAX 015- is a versatile single-pack product suitable for all plastic parts commonly found on vehicle exteriors.

Properties:

Easy to apply.

Good adhesion.

High elasticity

Technical data sheet

Substrate

Suitable substrates:

All plastic parts commonly found on vehicle exteriors (PP, EPDM, ABS, PC, PPO, PA, R-TPU, PBTP, PVC, PUR, PUR flexible foam, UP-GF).

Substrate pre-treatment:

The substrate must be free of release agents.

Before cleaning plastic parts, temper them for 60 minutes at +60 °C to “sweat out” the release agents.

–	Clean with anti-static plastic cleaner -LVM 001 001 A2- or with the milder slow-drying silicone remover -LVM 020 100 A5-.

Note

The effort required for the necessary cleaning depends on the type and quantity of the release agent used. It is recommended to use an emery pad to help in cleaning.

Let the thinner evaporate completely (e.g. air-dry overnight at ambient temperature or for 30-40 minutes at +60 °C).

Adhesion promoter

–	Before priming, clean lightly once more with anti-static plastic cleaner -LVM 001 001 A2- or slow-drying silicone remover -LVM 020 100 A5- (with anti-static effect).

Adhesion promoter

Application

Application:

–	Vigorously shake can for at least 2 minutes.

Adhesion promoter

Method of application: “spray”.

–	Apply one full coat (1-2 µm).

Spraying distance:

–	Maintain a distance of 20-25 cm.

Adhesion promoter

Flash-off time is 10-15 minutes at +20 °C ambient temperature.

Note

If spray work must be interrupted, ensure that the nozzle is cleared to avoid clogging by inverting the can and spraying until the valve is empty.

When treating small sand-through spots (max. 5.0 cm in diameter), the adhesion promoter -LLS MAX 015- can be recoated with top coat right away.

Finishing

Treat with:

Elastic 2-pack HS surfacer (for elasticisation, see relevant data sheet).

Recoat with:

2-pack HS top coat

Waterborne base coat and 2-pack HS clear coats

Caution

Protective garments and equipment in accordance with work safety regulations must be worn.

Observe safety information sheets as well as warnings on the label of the spray can.

Shake briefly before spraying each coat.

After fully emptying the spray can, dispose of as recycling material

Data

Adhesion promoter

VOC content: 2004/42/IIB(e)(840)730

The EU limit value for this product (product category IIB.e) in ready-to-spray form is max. 840 g/l of volatile organic compounds. The VOC content of this product in ready-to-spray form is max. 730 g/l.

Storage

The guaranteed shelf life is 60 months from date of production. May be used until the date stated on the label at latest if stored in sealed original containers at +20 °C.

Adhesion promoter

Storage conditions

The recommended storage temperature for this product is +20 °C to +25 °C (the temperature must not be below +5 °C).

Adhesion promoter
