Volkswagen Golf Service & Repair Manual: Removing and installing valve, rubber valve

Ensure that the wheel rim is clean.

–  Insert new tyre valve with -VAS 6459--1-.
–  Unscrew and remove valve insert.
–  Inflate tyre to approx. 3 to 4 bar. The bead of the tyre must slip audibly over the hump of the rim.
–  Screw in valve insert.
–  Check tyre pressure to make sure prescribed pressure has been reached.
–  Balance wheel.
